Description
Precoated Flow Rate (Filtering Capacity) |
600 gph |
Open Pumping Capacity |
2,400 gph |
Filtration Surface Area |
7 ft² |
Number of Filter Media |
20 |
Filter Media Diameter |
8-1/8 “ |
Sludge Holding Capacity |
123 in³ |
Approximate Length |
40 “ |
Approximate Width |
16 “ |
Approximate Height |
36 “ |
Approximate (Crated) Net Weight |
290 lbs |
Hose Connection Suction |
1-1/2 “ |
Hose Connection Discharge |
1-1/4 “ |
Hose Length |
10 ft |
TEFC Motor |
1 hp |
Pump Options |
PPM – Magnetic End Suction Pump – Standard
PPQ – Magnetic Self-Priming Pump – Adder PPS – Mechanical Seal CRS-40-PP – No Extra Charge |
Slurry Tank Option |
NO SLURRY TANK – Standard
WITH SLURRY TANK – Adder |
