Back to Series PP Filter System
Mefiag PPQ

Mefiag 3500-PPQ and 3500-PPQ-SY Horizontal Disc Filtration Systems

Call for Price

SKU: 3500-PPQand3500-PPQ-SY Categories: ,

Description

Precoated Flow Rate (Filtering Capacity)

 3,500 gph

Open Pumping Capacity

 5,400 gph

Filtration Surface Area

 32 ft²

Number of Filter Media

 48

Filter Media Diameter

 12 “

Sludge Holding Capacity

 806 in³

Approximate Length

 43 “

Approximate Width

 20 “

Approximate Height

 53 “

Approximate (Crated) Weight

 550 lbs

Hose Connection Suction

 2 in Inlet

Hose Connection Discharge

 1-1/2 in Outlet

Hose Length

 20 ft

Motor (TEFC)

 2 hp

Pump Options

 PPQ – Magnetic Self-Priming Pump – Standard

PPS – Mechanical Seal CRS-40-PP – No Extra Charge

Slurry Tank Option

 NO SLURRY TANK – Standard

WITH SLURRY TANK – Adder
