Description
Precoated Flow Rate (Filtering Capacity) |
18,000 gph |
Open Pumping Capacity |
26,000 gph |
Filtration Surface Area |
178 ft² |
Number of Filter Media |
100 |
Filter Media Diameter |
19 “ |
Sludge Holding Capacity |
4.77 ft³ |
Length |
90 “ |
Width |
55 “ |
Height |
55 “ |
System Connections Suction |
(2) 3″ NPT (Female) |
System Connections Discharge |
(2) 2″ NPT (Female) |
| Motor (TEFC)1 | 5 HP Fybroc Series 1530 (Two Motors) |
Pump Options |
FYBROC 1530 Fiberglass Pump – Standard |
Slurry Tank Option |
WITH SLURRY TANK – Standard |
Weight |
2100 lbs |
